Sku:N/A

034Motorsport S34 Carbon Fibre Intake - B8/8.5 Q5/SQ5 3.0 TFSI

£422.98
£469.98
Tax included
Sale
-10%

DESCRIPTION

Availability

Shipping & Warranty

Elevate Your Audi's Performance with the 034Motorsport S34 Carbon Fibre Intake


Experience the power and sophistication of carbon fibre with the 034Motorsport S34 Carbon Fibre Intake designed specifically for the B8/8.5 Q5/SQ5 3.0 TFSI. Enhance your Audi's performance with this premium intake system, crafted with precision engineering and advanced materials to deliver exceptional results.

Unleash Greater Airflow: The 034Motorsport S34 Carbon Fibre Intake optimises airflow to your Audi's engine, unlocking its true potential. Constructed from lightweight and durable carbon fibre, this intake system reduces intake air temperatures and increases air volume, resulting in improved performance and throttle response. Prepare to experience exhilarating acceleration and a more engaging driving experience.

Superior Design, Outstanding Quality: Crafted with meticulous attention to detail, the 034Motorsport S34 Carbon Fibre Intake combines stunning aesthetics with exceptional functionality. The carbon fibre construction not only provides a visually striking appearance but also offers unmatched strength and durability. Rest assured, this intake system is built to withstand the demands of enthusiastic driving while adding a touch of elegance under the bonnet.

Easy Installation, Instant Benefits: Installing the 034Motorsport S34 Carbon Fibre Intake is a breeze, thanks to its precise fitment and comprehensive installation instructions. Designed as a direct replacement for the factory intake system, it requires no modifications, ensuring a hassle-free installation process. Once installed, you'll immediately notice the enhanced performance and the distinct growl that accompanies every acceleration.

Unmatched Performance, Unforgettable Sound: The 034Motorsport S34 Carbon Fibre Intake not only improves your Audi's performance but also enhances its auditory experience. Enjoy the deep, resonant engine note that accompanies the increased airflow, adding a sporty soundtrack to your driving adventures. Every journey will be filled with the captivating symphony of power and performance.

Unlock the Potential of Your Audi: Upgrade your B8/8.5 Q5/SQ5 3.0 TFSI with the 034Motorsport S34 Carbon Fibre Intake and unleash the true potential of your Audi. Experience improved power, enhanced throttle response, and an aggressive engine note that commands attention. Elevate your driving experience with this premium carbon fibre intake system and indulge in the ultimate combination of performance and style.



Specification

PRESSURE DROP IMPROVEMENTS:

Pressure Drop is the difference in ambient air pressure and the air pressure measured at the supercharger inlet across the engine's rpm range. The higher the pressure drop at any given rpm, the more restrictive the intake system is, reducing airflow.

Intake Configuration Chart Color Pressure Drop
S34 Carbon Fibre Intake Yellow -0.97 psi
Stock Intake White -2.18 psi


CFM GAINS:

CFM stands for "cubic feet per minute" of airflow, the higher the number, the higher the horsepower an intake can support, at 034Motorsport we design our intakes to have substantial flow increases over the factory intake, we test all our intakes at 28" of water (how much vacuum is used to suck air through the intake) on a Superflow airflow bench which gives us very accurate and repeatable test results. A stock intake that flows 200CFM may only freely support about 300HP, an intake that flows 400CFM can support roughly twice that power or 600HP.

  • Stock Intake: 542 CFM @ 28” H2O
  • S34 Intake: 946 CFM @ 28” H2O

DYNO-VERIFIED WHEEL HORSEPOWER & TORQUE GAINS:

034Motorsport's engineering and development efforts were validated on multiple vehicles using our Mustang AWD Dynamometer to ensure that the S34 Carbon Fibre Intake provided substantial increases in horsepower and torque on both stock supercharger and ones with ported supercharger kits alike.

PEAK WHEEL HORSEPOWER & TORQUE WITH STAGE 2+ E40, 57.75/190MM PULLEY COMBO:

  • Stock Intake: 416 WHP / 396 WTQ
  • S34 Carbon Fibre Intake: 436 WHP / 416 WTQ
  • Peak Crank Gains: 26 HP / 24 TQ
